Lapping Machine
Features
Reliability for thickness control system
Anti-Vibration design
Provides user friendly condition
Active pressure control by Air actuator & Load-cell
Easy surface-quality-control by pressure control at each step
Realized the top productivity by Low-price & high efficiency structure
Specifications
| Model | 36B4R | 50B4R | ||
| Ceramic Jig Size | Ø360 | Ø485 | ||
| Plate | Size | DMP | Ø910mm | Ø1250mm |
| CMP | Ø910mm | Ø1270mm | ||
| Material | DMP | Pure/Resin copper, Metal Tin | ||
| CMP | Stainless Steel | |||
| Wheel Spindle | DMP | 11kW | 20kW | |
| CMP | 15kW | 25kW | ||
| Pressure Unit | Cylinder | 4 station | ||
| Auto Facing Unit | RPM | Min. 1mm/min~Max. 300mm/min | ||
| for DMP | ||||
| Dimension | DMP | 1430(W) x 2340(D) x 2002(H)mm | 2260(W) x 3244(D) x 2830(H)mm | |
| CMP | 1430(W) x 1620(D) x 2162(H)mm | 2120(W) x 2700(D) x 2863(H)mm | ||
| Weight | DMP | approx. 3500kg | approx. 7000kg | |
| CMP | approx. 2500kg | approx. 7000kg | ||
